A fosfomycin plus tobramycin combination formulation for delivery by aerosolization is described. The concentrated fosfomycin tobramycin combination formulation containing an efficacious amount of fosfomycin plus tobramycin is able to inhibit susceptible bacteria. Fosfomycin and tobramycin are formulated separately in a dual ampoule such that when reconstituted, the pH is between 4.5 and 8.0 or as a dry powder. The method for treatment of respiratory tract infections by a formulation delivered as an aerosol having mass median aerodynamic diameter predominantly between 1 to 5, produced by a jet or ultrasonic nebulizer (or equivalent) or dry powder inhaler.
1. A method of treating a patient in need thereof, comprising administering to said patient a therapeutically effective amount of an aerosol formulation consisting of from about 1 to about 300 mg of fosfomycin and from about 1 to about 300 mg of tobramycin in a physiologically acceptable solution wherein the weight ratio is from about 7 parts by weight of fosfomycin to about 3 parts by weight of tobramycin; or from about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin; or from about 9 parts by weight of fosfomycin to about 1 part by weight of tobramycin, wherein said formulation is suitable for administration by a nebulizer or dry powder inhaler, wherein the patient is treated. 2. The method according to 3. The method according to 4. A method of treating a patient in need thereof, comprising administering to said patient a therapeutically effective amount of an aerosol formulation consisting of fosfomycin and tobramycin in a physiologically acceptable solution wherein the weight ratio is about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin, wherein said formulation is administered using a nebulizer, wherein the patient is treated. 5. A method for treatment of an infection caused by bacteria in the respiratory tract of a human in need thereof, said method comprising administering to said human a therapeutically effective amount of an aerosol formulation consisting of from about 1 to about 300 mg of fosfomycin and from about 1 to about 300 mg of tobramycin in a physiologically acceptable solution wherein the weight ratio is from about 7 parts by weight of fosfomycin to about 3 parts by weight of tobramycin; or from about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin; or from about 9 parts by weight of fosfomycin to about 1 part by weight of tobramycin, using a nebulizer, wherein the human is treated. 6. The method according to 7. The method according to 8. The method according to 9. The method according to 10. A method for treatment of an infection caused by bacteria in the respiratory tract of a human in need thereof, said method comprising administering to said human a therapeutically effective amount of an aerosol formulation consisting of fosfomycin and tobramycin in a physiologically acceptable solution wherein the weight ratio is about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin, wherein said formulation is administered using a nebulizer, wherein the human is treated. 11. The method according to 12. The method according to 13. The method according to 14. A method for treatment of a respiratory bacterial infection caused by methicillin-resistant 15. A method for treatment of a pulmonary infection in a cystic fibrosis patient in need thereof, said method comprising administering to said patient a therapeutically effective amount of an aerosol formulation according consisting of from about 1 to about 300 mg of fosfomycin and from about 1 to about 300 mg of tobramycin in a physiologically acceptable solution wherein the weight ratio is from about 7 parts by weight of fosfomycin to about 3 parts by weight of tobramycin; or from about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin; or from about 9 parts by weight of fosfomycin to about 1 part by weight of tobramycin, using a nebulizer, wherein the human is treated. 16. The method according to 17. The method according to 18. A method for treatment of a pulmonary infection in a cystic fibrosis patient in need thereof, said method comprising administering to said patient a therapeutically effective amount of an aerosol formulation consisting of fosfomycin and tobramycin in a physiologically acceptable solution wherein the weight ratio is about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin, wherein said formulation is administered using a nebulizer, wherein the patient is treated. 19. A method for treatment of chronic pulmonary 20. The method according to 21. The method according to 22. A method for treatment of chronic pulmonary 23. A method for treatment of bronchiectasis in a human in need thereof, said method comprising administering to said human a therapeutically effective amount of an aerosol formulation consisting of from about 1 to about 300 mg of fosfomycin and from about 1 to about 300 mg of tobramycin in a physiologically acceptable solution wherein the weight ratio is from about 7 parts by weight of fosfomycin to about 3 parts by weight of tobramycin; or from about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin; or from about 9 parts by weight of fosfomycin to about 1 part by weight of tobramycin, using a nebulizer, wherein the human is treated. 24. The method according to 25. The method according to 26. A method for treatment of bronchiectasis in a human in need thereof, said method comprising administering to said human a therapeutically effective amount of an aerosol formulation consisting of fosfomycin and tobramycin in a physiologically acceptable solution wherein the weight ratio is about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin, wherein said formulation is administered using a nebulizer, wherein the human is treated. 27. A method for treatment of ventilator associated pneumonia in a human in need thereof, said method comprising administering to said human a therapeutically effective amount of an aerosol formulation consisting of from about 1 to about 300 mg of fosfomycin and from about 1 to about 300 mg of tobramycin in a physiologically acceptable solution wherein the weight ratio is from about 7 parts by weight of fosfomycin to about 3 parts by weight of tobramycin; or from about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin; or from about 9 parts by weight of fosfomycin to about 1 part by weight of tobramycin, using a nebulizer, wherein the human is treated. 28. The method according to 29. The method according to 30. A method for treatment of ventilator associated pneumonia in a human in need thereof, said method comprising administering to said human a therapeutically effective amount of an aerosol formulation consisting of fosfomycin and tobramycin in a physiologically acceptable solution wherein the weight ratio is about 8 parts by weight of fosfomycin to about 2 parts by weight of tobramycin, wherein said formulation is administered using a nebulizer, wherein the human is treated. 31. A method for treatment of respiratory bacterial infections caused by multidrug-resistant 32. A method for treatment of respiratory bacterial infections caused by multidrug-resistant
This application is a divisional of U.S. patent application Ser. No. 11/596,566, filed 15 Nov. 2006, which application is a U.S. national Stage filing of International Application No. PCT/US2005/014690 filed May 2, 2005, which claims priority of U.S. Ser. Nos. 60/571,739 filed May 17, 2004 and 60/659,005 filed Mar. 3, 2005, the disclosures of which are incorporated herein by reference. The current invention concerns a novel, safe, nonirritating and physiologically compatible inhalable fosfomycin plus aminoglycoside combination formulation suitable for treatment of respiratory bacterial infections caused by Gram-negative bacteria, such as The most widely accepted therapy for treating respiratory infections caused by Gram-negative bacteria in cystic fibrosis patients involves intravenous administration of a single antibiotic or combinations of antibiotics (Gibson et al., 2003; Ramsey, 1996). This method of treatment has several significant limitations including: (1) narrow spectrum of activity of existing antibiotics, (2) insufficient concentrations of antibiotic reaching the respiratory tract to ensure rapid onset and high rates of bacterial killing, and (3) development of adverse side affects due to high systemic concentrations of drug. Aerosol administration of antibiotics (Conway, 2005; O'Riordan, 2000) addresses several of the limitations of parenteral administration (Flume and Klepser, 2002; Kuhn, 2001). It enables topical delivery of high concentrations of drug to the endobronchial spaces and reduces side effects by lowering systemic exposure to antibiotic. However, cystic fibrosis patients typically receive prolonged and repeated antibiotic therapies over the entire duration of their adult lives (Gibson et al., 2003; Ramsey, 1996). Therefore, cummulative aminoglycoside toxicity and development of resistance remains a significant problem. Fosfomycin Fosfomycin is a broad spectrum phosphonic acid antibiotic (Kahan et. al., 1974; Woodruff et al., 1977) that has bactericidal activity against Gram-negative bacteria including Fosfomycin is bactericidal but exhibits time-dependent killing against Fosfomycin monotherapy is commonly used in the treatment of uncomplicated urinary tract infections caused by Fosfomycin is available in both oral (fosfomycin calcium and fosfomycin trometamol) and intravenous (fosfomycin disodium) formulations (Woodruff et al., 1977). Fosfomycin trometamol is the preferred formulation for oral administration because it is more readily absorbed into the blood compared to fosfomycin calcium. Following a single intravenous or intramuscular dose of 2 g of fosfomycin, peak serum concentrations range between 25-95 μg/mL within 1-2 hours (Woodruff et al., 1977). By comparison, concentrations reach 1-13 μg/mL in normal lung after parenteral administration of a comparable dose of fosfomycin (Bonora et al., 1977) which is an insufficient to kill most bacterial pathogens, in particular Fosfomycin is widely distributed in various body tissues and fluids but does not significantly bind to plasma proteins (Mirakhur et al., 2003). Consequently, fosfomycin is available to exert antibacterial effects if it reaches sufficient concentrations at the site of infection. The respiratory tract of cystic fibrosis patients are obstructed with viscous secretions called sputum (Ramsey, 1996). The effectiveness of several classes of antibiotics such as aminoglycosides and β-lactams is reduced due to poor penetration into sputum. Additionally, the activity of these antibiotics is further reduced by binding to sputum components (Hunt et al., 1995; Kuhn, 2001; Ramphal et al., 1988; Mendelman et al., 1985). Development of resistance in bacteria isolated from patients treated with fosfomycin for urinary tract infections occurs very infrequently (Marchese et al., 2003). Cross-resistance with other classes of cell wall inhibiting antibiotics does not occur because fosfomycin acts on the enzyme phosphoenolpyruvate (UDP-N-acetylglucosamine enolpyruval-transferase) which is not targeted by other antibiotics (Kahan et al., 1974; Woodruff et al., 1977). Fosfomycin is actively taken up into bacterial cells by two transport systems; a constitutively functional L-α-glycerophosphate transport and the hexose-phosphate uptake system (Kahan et al., 1974). When fosfomycin resistance occurs, it is typically due to a genetic mutation in one or both of the chromosomally encoded transport systems, and less commonly by modifying enzymes (Arca et al., 1997; Nilsson et al., 2003). Tobramycin. Tobramycin is an aminoglycoside antibiotic that is active against Gram-negative aerobic bacilli including Tobramycin is rapidly bactericidal and exhibits concentration-dependent killing (Vakulenko and Mobashery, 2003). Increasing the tobramycin concentration increases both the rate and extent of bacterial killing. Therefore, to achieve therapeutic success, it is necessary to administer a large enough dose to produce a peak tobramycin level 5-10 times greater than the MIC of the target organism at the site of infection. It is preferable to treat Tobramycin is usually administered to treat less serious Gram-negative bacterial infections (Vakulenko and Mobashery, 2003). However, it may be combined with other classes of antibiotics to treat severe infections of the urinary tract and abdomen, as well as endocarditis and bacteremia (Vakulenko and Mobashery, 2003). Parenteral administration of tobramycin in combination with cell-wall inhibiting antibiotics has been used to treat respiratory infections, in particular those caused by Tobramycin is poorly absorbed orally and must be administered parenterally (Hammett-Stabler and Johns, 1998). Tobramycin is available in both intravenous and aerosol formulations. After parenteral administration, tobramycin is primarily distributed within the extracellular fluid. Tobramycin is rapidly excreted by glomular filtration resulting in a plasma half-life of 1-2 hours (Tan et al., 2003). Penetration of tobramycin into respiratory secretions is very poor and its activity is further reduced by binding to sputum (Kuhn, 2001). Aerosol administration of tobramycin results in significantly higher sputum levels of ≧1000 μg/mL (Geller et al., 2002) compared with parenteral administration, but sputum binding remains a significant problem (Hunt et al., 1995; Mendelman et al., 1985; Ramphal et al., 1988). Nephrotoxicity and ototoxicity are adverse reactions associated with tobramycin therapy (Al-Aloui et al., 2005; Hammett-Stabler and Johns, 1998). Nephrotoxicity results from accumulation of tobramycin within lysosomes of epithelial cells lining the proximal tubules. This causes an alteration of cell function and ultimately cell necrosis (Mingeot-Leclercq and Tulkens, 1999). Clinically, this presents as nonoliguric renal failure. The prevalence of nephrotoxicity in cystic fibrosis patients is estimated to be 31-42% (Al-Aloui et al., 2005). The incidence of ototoxicity, which is characterized by loss of hearing and dizziness, is estimated to be as high as 25% of patients treated with aminoglycosides (Hammett-Stabler and Johns, 1998). Unlike nephrotoxicity, ototoxicity is irreversible. The greatest risk factor for the development of toxicity is cumulative exposure to large doses of tobramycin (Hammett-Stabler and Johns, 1998; Mingeot-Leclercq and Tulkens, 1999). Cystic fibrosis patients are treated with prolonged and repeated high-dosages of tobramycin over their entire lifetime (Tan et al., 2003) and are at increased risk of developing cumulative renal failure (Al-Aloui et al., 2005). Bacterial resistance to tobramycin has become increasingly prevalent and is due to repeated and prolonged antibiotic monotherapy (Conway et al., 2003; Van Eldere, 2003; Mirakhur et al., 2003; Pitt et al., 2005; Schulin, 2002). For example, Cystic fibrosis patients are colonized with It is clear that there is a continued need for an improved method of treatment for acute and chronic respiratory infections caused by Gram-negative and Gram-positive bacteria, particularity multidrug resistant It would be highly advantageous to provide a formulation and system for delivery of a sufficient dose of fosfomycin plus an aminoglycoside such as tobramycin in a concentrated form, containing the smallest possible volume of solution or weight of dry powder which can be aerosolized and delivered predominantly to the endobronchial space. Thus, it is an objective of this invention to provide a concentrated liquid or dry powder formulation of fosfomycin plus aminoglycoside which contains sufficient but not excessive amounts of fosfomycin and aminoglycoside which can be efficiently aerosolized by nebulization into aerosol particles sizes predominantly within a range of 1 to 5 um and having salinity that is adjusted to permit generation of a fosfomycin plus aminoglycoside aerosol well tolerated by patients, and which has an adequate shelf live. One aspect of this invention is a method for treatment of upper respiratory tract infections like bacterial sinusitis and lower respiratory tract (pulmonary) infections like infections in cystic fibrosis, chronic pulmonary Another aspect of the current invention is a concentrated formulation either liquid or dry powder, suitable for delivery of a fosfomycin tobramycin combination into the endobronchial or nasal space of patients to treat lower and upper respiratory bacterial infections. Still another aspect of the current invention is a formulation, either liquid or dry powder, suitable for delivery of aminoglycoside and fosfomycin into the endobronchial and nasal space of patients that reduces the development of antibiotic resistance compared to either drug used alone. Still another aspect of the current invention is a formulation, either liquid or dry powder, suitable for delivery of an aminoglycoside and fosfomycin into the endobronchial or nasal space of patients that increases the post antibiotic affect (PAE) compared to the PAE of either the drug used alone. Still another aspect of the current invention is a formulation comprising from 1-300 mg of fosfomycin and from 1 to 300 mg aminoglycoside in 0.5 to 7 mL of water with a chloride concentration >30 mM wherein said formulation has a pH between 4.5 and 8.0 and is delivered by aerosolization. The aerosol contains particles that have a mass median aerodynamic diameter (MMAD) predominantly between 1 to 5μ and is administered using a nebulizer able to atomize the particles of the required size. Still another aspect of the current invention is a dry powder formulation comprising from about 1 to about 300 mg of fosfomycin, from about 1 to about 300 mg aminoglycoside and at least one pharmaceutically acceptable excipient in a micronized dry powder form that delivers particles with a MMAD of 1 and 5μ upon aerosolization. The invention concerns an inhalable formulation comprising fosfomycin plus an aminoglycoside suitable for treatment of acute and chronic pulmonary bacterial infections, particularly those caused by the multidrug resistant Gram-negative bacteria The formulations of the present invention preferably comprise from 5 to 9 parts by weight fosfomycin and 1 to 5 parts by weight aminoglycoside, preferably from about 7 to 9 parts by weight fosfomycin and 1 to 3 parts by weight aminoglycoside and more preferably about 8 parts by weight fosfomycin and about 2 parts by weight aminoglycoside. The most preferred aminoglycoside is tobramycin. As used herein: “Quarter normal saline” or “¼ NS” means normal saline diluted to its quarter strength containing 0.225% (w/v) NaCl. “9:1 fosfomycin:tobramycin” means a water solution or dry powder formulation containing a 9:1 ratio by weight of fosfomycin acid to tobramycin base. “8:2 fosfomycin:tobramycin” means a water solution or dry powder formulation containing a 8:2 ratio by weight of fosfomycin acid to tobramycin base such that the amount of fosfomycin is four times the amount of tobramycin. “7:3 fosfomycin:tobramycin” means a water solution or dry powder formulation containing a 7:3 ratio by weight of fosfomycin acid to tobramycin base. “5:5 fosfomycin:tobramycin” means a water solution or dry powder formulation containing a 5:5 ratio by weight of fosfomycin acid to tobramycin base. “Minimal inhibitory concentration (MIC)” means the lowest concentration of antibiotic (s) that prevents visible growth after incubation for 18-20 hours at 35° C. “Minimal bactericidal concentration (MIC)” means the lowest concentration of antibiotic that results in ≧3 Log10of bacterial killing. “Time-dependent killing” means higher drug concentrations do not kill bacteria any faster or to a greater extent. Concentration-dependent killing″ means the higher the drug concentration, the greater the rate and extent of bacterial killing. “Bacteriostatic” means the antibiotic acts by inhibiting bacterial growth. “Bactericidal” means the antibiotics acts by killing bacteria. “Synergy” means the combined effect of the antibiotics being examined is significantly greater than either drug alone. The current invention concerns a concentrated fosofomycin plus tobramycin formulation suitable for efficacious delivery by aerosolization into the endobronchial or nasal space. The invention is preferably suitable for formulation of concentrated fosfomycin plus tobramycin for aerosolization by jet, ultrasonic, or equivalent nebulizers to produce aerosol particles between 1 and 5μ necessary for the efficacious delivery of fosfomycin plus tobramycin into the endobronchial or nasal space to treat bacterial infections, particularly those caused by multidrug-resistant Primary requirements for any aerosolized formulation are its safety and efficacy. Additional advantages are lower cost, practicality of use, long shelf-life, storage and manipulation of nebulizer. Aerosolized fosfomycin plus tobramycin is formulated for efficacious delivery of fosfomycin plus tobramycin to the lung endobronchial or nasal space. A nebulizer is selected to allow the formation of a fosfomycin plus tobramycin aerosol having a mass median aerodynamic diameter predominantly between 1 to 5μ. The formulated and delivered amount of fosfomycin plus tobramycin is efficacious for the treatment of bacterial pulmonary infections, particularly those caused by multi-drug resistant I. Evaluation of the Antibiotic Combinations Fosfomycin: aminoglycosides combinations were formulated as described in Example 1. Fosfomycin comprised the major component of the combination because of it's inherent safety and the need to reduce the toxicity of the aminoglycoside. The fosfomycin:aminoglycoside combinations, in particular fosfomycin:tobramycin were evaluated for (a.) in vitro potency, (b.) killing rates, (c.) frequency of resistance, and (d.) animal efficacy. a. In Vitro Potency The in vitro potency of fosfomycin and tobramycin alone and in combination against a panel of Gram-negative and Gram-positive bacteria representative of species that cause respiratory tract infections in cystic fibrosis, bronchiectasis, sinusitis and ventilator-associated Table 3 shows the MIC50and MIC90values of fosfomycin and tobramycin alone and in combination for 100 Table 4 shows the results of checkerboard synergy studies between fosfomycin and nine aminoglycosides. The interactions between the nine different fosfomycin:aminoglycoside combinations were all classified as indifferent. None of the combinations had synergistic activity against Table 5 shows the results of checkerboard synergy studies between fosfomycin and tobramycin against clinical strains of Table 6 shows the MBC/MIC values of fosfomycin and tobramycin alone and 9:1, 8:2, and 7:3 fosfomycin:tobramycin combinations for Table 7 shows the MBC/MIC values of fosfomycin and tobramycin alone and 9:1, 8:2, and 7:3 combinations for Table 8 shows the results of time-kill studies of 9:1, 8:2, and 7:3 fosfomycin:aminoglycoside combinations against Table 9 shows the time to achieve bactericidal killing of c. Frequency of Resistance Table 10 shows the frequency of development of resistance to fosfomycin and tobramycin alone, and a 9:1 fosfomycin:tobramycin combination for five Table 11 shows the fold increase in the MIC of Table 12 shows the development of resistance in a clinical II. Aerosol Fosfomycin/Tobramycin Formulation Aminoglycosides useful in the invention are antibiotics, such as tobramycin, gentamicin, kanamycin B, amikacin, arbekacin, dibekacin, streptomycin, neomycin, and netilmicin. Fosfomycin compounds particularly useful in the invention are antibiotics, such as fosfomycin trometamol, fosfomycin disodium salt, and fosfomycin calcium. The preferred fosfomycin plus tobramycin formulation according to the invention contains 10-500 mg of fosfomycin plus tobramycin per 0.5-7 mL of water with a chloride concentration >30 mM. This corresponds to doses that would be required to prevent colonization or to treat severe upper and lower respiratory tract infections caused by a range of susceptible organisms. Patients can be sensitive to the pH, osmolarity, and ionic content of a nebulized solution. Therefore these parameters should be adjusted to be compatible with fosfomycin plus tobramycin and tolerable to patients. The most preferred solution or suspension of fosfomycin plus tobramycin will contain a chloride concentration >30 mM at pH 4.5-8.0. The formulation of the invention is nebulized predominantly into particle sizes allowing delivery of the drug into the terminal and respiratory bronchioles or nasal passages where the bacteria reside during infection and colonization. For efficacious delivery of fosfomycin plus tobramycin to the lung endobronchial space of airways in an aerosol, the formation of an aerosol having a mass median aerodynamic diameter predominantly between 1 to 5μ is necessary. The formulated and delivered amount of fosfomycin plus tobramycin for the treatment and prophylaxis of endobronchial infections, particularly those caused by the According to the invention, fosfomycin plus tobramycin is formulated in a liquid dosage form intended for inhalation therapy by patients with, or at risk to acquire, bacterial upper or lower respiratory infection. Since the patients reside throughout the world, it is imperative that the liquid dosage formulation has reasonably long shelf-life. Storage conditions and packaging thus become important. The formulation of fosfomycin plus tobramycin can be aseptically prepared as an aqueous solution in a dual blow-fill ampoule such that each antibiotic is independently formulated in water and pH adjusted. Tobramycin is formulated at acidic pH (1-6) while fosfomycin is formulated at basic pH (8-13). The low pH formulation for tobramycin assures that all of its basic nitrogen atoms are protonated thus protecting the molecule from amine oxidation and degradation (tobramycin solutions turn yellow at room temperature). Thus, the low pH solutions of tobramycin are stable at room temperature for indefinite periods of time. Fosfomycin is most stable at high pH as the reactive epoxide ring is prone to hydrolysis (ring opening) at acidic or low pH. High pH solutions of fosfomycin are also stable at room temperature. Therefore, the dual ampoule blow-fill container allows for the separate and room temperature stable formulation of each antibiotic at high and low pH such that the drug product combination and final pH is created by mixing both solutions in the nebulizer immediately before use. The storage suitability of the formulation allows reliable usage of the formulated fosfomycin plus tobramycin suitable for aerosolization. III. Nebulizers for Pulmonary Delivery of the Antibiotic Combination A device able to nebulize the formulation of the invention into aerosol particles predominantly in the 1 to 5μ size range is utilized to administer the formulations of the present invention. Predominantly in this application means that at least 70% but preferably more than 90% of all generated aerosol particles are within the 1 to 5μ range. Typical devices include jet nebulizers, ultrasonic nebulizers, pressurized aerosol generating nebulizers, and vibrating porous plate nebulizers. Representative suitable nebulizers include the eFlow® nebulizer available from Pari Inovative Manufactures, Midlothian, Va.; the iNeb® nebulizer available from Profile Drug Delivery of West Sussex, United Kingdom; the Omeron MicroAir® nebulizer available from Omeron, Inc. of Chicago, Ill. and the AeroNebGo® nebulizer available from Aerogen Inc. of Mountain View, Calif. A jet nebulizer utilizes air pressure to break a liquid solution into aerosol droplets. An ultrasonic nebulizer works by a piezoelectric crystal that shears a liquid into small aerosol droplets. Pressurized systems general force solutions through small pores to generate small particles. A vibrationg porous plate device utilizes rapid vibration to shear a stream of liquid into appropriate droplet sizes. However, only some formulations of fosfomycin plus tobramycin can be efficiently nebulized as the devices are sensitive to the physical and chemical properties of the formulation. The invention is a small volume, high concentration formulation of fosfomycin plus tobramycin that can be delivered as an aerosol at efficacious concentrations of the drug to the respiratory tract in people at risk for, or suffering from infection caused by susceptible bacteria. The formulation is safe, well tolerated, and very cost effective. Furthermore, the formulation provides adequate shelf life for commercial distribution. The foregoing may be better understood from the following examples, which are presented for the purposes of illustration and are not intended to limit the scope of the inventive concepts. 9:1 Fosfomycin/Tobramycin Solution Fosfomycin disodium (18.057 g, 13.99 g free acid) was dissolved in 250 mL of water and the pH was adjusted to 7.41 by the dropwise addition of 1.53 mL of 4.5 N HCl. To the resulting solution was added 1.56 g of 97.5% tobramycin base. The pH of the solution was adjusted to 7.60 by the addition of 2.45 mL of 4.5 N HCl. The solution was diluted to 500 mL with water and filtered through a 0.2 μm Nalge Nunc 167-0020 membrane filter. The final pH was 7.76, the osmolality was 537 mOsmol/kg, the fosfomycin/tobramycin ratio was calculated to be 9:1, and the chloride concentration was 35.8 mM.
7.9165 g of fosfomycin disodium (6.0007 g of fosfomycin free acid) and 1.5382 g of 97.5% tobramycin base (1.4997 g of pure tobramycin base) were dissolved in 50 mL water. The pH was adjusted to 7.62 by the addition of 2.3 mL of 6 M HCl. The combined solution was diluted to 100 mL. The final pH was 7.64, the osmolality was 1215 mOsmol/kg, the final chloride concentration was 138 mM, and the fosfomycin/tobramycin ratio was 8:2. A fosfomycin solution was prepared by dissolving 5.891 g of fosfomycin disodium (4.465 g of fosfomycin free acid) in water and diluting to 100 mL. The pH was 9.42, and the osmolality was 795 mOsmol/kg. A tobramycin solution was prepared by dissolving 1.869 g of 97.5% tobramycin base (1.822 g of pure tobramycin base) in 60 mL water, adjusting the pH to 4.90 by adding 18.8 mL of 1 M HCl, and diluting to 100 ml with water. The pH was 4.89, and the osmolality was 148 mOsmol/kg. 1 mL of the fosfomycin solution and 1 mL of the tobramycin solution were combined. For the combined drug product solution, the pH was 7.30, the osmolality was 477 mOsmol/kg, the chloride concentration was 94.0 mM, and the fosfomycin/tobramycin ratio was 7:3. 3.1665 g of fosfomycin disodium (FOSFO, 2.4002 g of fosfomycin free acid) was dissolved in two 5 mL (60 mg/mL) ampoules of Tobramycin Solution for Inhalation (TOBI, 600 mg of tobramycin base) plus 40 mL water. The initial pH of the solution was 7.50. To the solution was added 667 μl of 4.5 M NaCl. The combined solution was diluted to 100 mL with water. The final formulation had the following properties; pH 7.49, osmolality 502 mOsmol/kg, chloride concentration 33.8 mM, and the fosfomycin/tobramycin ratio was 8:2, and drug concentration of 24 mg/mL fosfomycin and 6 mg/mL of trobramycin. Examples 5-10 set forth the procedures that have been used to generate the date presented in the Tables and Figures of this application. The efficacy of antibiotics and antibiotic combinations against Gram-positive and Gram-negative bacteria representative of species that cause respiratory infections in patients with cystic fibrosis, bronchiectasis, sinusitis, and ventilator-associated pneumonia were evaluated in MIC assays. Method A: The MICs of fosfomycin alone, tobramycin alone, or combinations of fosfomycin plus tobramycin were determined by the agar-plate dilution method according to NCCLS guidelines (NCCLS, 2003). Bacterial strains were streaked onto Trypic Soy Agar plates (PML Microbiologicals, Wilsonville, Or.) containing 5% defibrinated sheep blood (hereafter referred to as blood agar plates) and incubated overnight at 35° C. Two to three bacterial colonies from the overnight cultures were inoculated into 3 mL of sterile normal saline, vortexed briefly, and adjusted to a 0.5 McFarland standard (NCCLS, 2003). The bacterial suspension was diluted 1:40 in sterile normal saline and served as the inoculum. Mueller-Hinton agar plates (hereafter referred to as MHA) were prepared by combining 16 g of agarose (Becton-Dickinson, Sparks, Md.), 22 g of Mueller-Hinton broth powder (Becton-Dickinson, Sparks, Md.), and adjusted to 1 L with distilled water. The agar was sterilized by autoclaving, cooled to 55° C., and supplemented with 25 μg/mL of glucose-6-phosphate (Sigma-Aldrich, St. Louis, Mo.). Twenty-five mL of cooled agar was aliquoted into 50 mL conical tubes and supplemented with appropriate concentrations of antibiotic to achieve concentrations ranging from 0.06 μg/mL to 512 μg/mL. After gently mixing the agar and antibiotic, the suspension was poured into sterile 100 mm petri dishes and allowed to solidify at room temperature. The antibiotic agar plates were inoculated with approximately 2×104CFU/spot with a 48-point inoculator (Sigma-Aldrich, St. Louis, Mo.). The MIC was defined as the lowest concentration of antibiotic (s) that prevented visible growth after incubation for 18-20 hours at 35° C. The efficacy of a particular antibiotic or antibiotic combination on large populations of Potential interactions between fosfomycin and amikacin, arbekacin, dibekacin, gentamicin, kanamycin B, neomycin, netilimicin, streptomycin, or tobramycin were determined by the checkerboard method (Eliopoulos and Moellering, 1996). Two-fold serial dilutions of fosfomycin and aminoglycosides, which bracketed the expected MIC value for both compounds, were evaluated. Bacterial strains were streaked onto blood agar plates and incubated at 35° C. for 18-24 hours. Two to three bacterial colonies from the overnight cultures were inoculated into 3 mL of sterile normal saline, vortexed briefly, and adjusted to a 0.5 McFarland standard (NCCLS, 2003). Fifty microliters of bacterial inoculum (approximately 2×105CFU/mL) was pipeted into individual wells of 96-well plates containing 50 μl of CAMHB supplemented with 2-fold dilutions of the two antibiotics of interest. The fractional inhibitory concentration (FIC) was calculated as the MIC of compound #1 in combination with a second compound, divided by the MIC of compound #1 alone. A summation of FIC (SFIC) was calculated for each drug combination as the sum of the individual FICs of compound #1 and #2. The FIC was calculated as the lowest concentration of antibiotics that that prevented visible growth after incubation at 18-20 hours at 35° C. Synergy was defined as an SFIC of ≦0.5, indifference as an SFIC>0.5 and <4, and antagonism as an SFIC>4. The lowest SFIC was used for final interpretation of drug interactions. Time-kill experiments were performed in the presence of 2% porcine gastric mucin to evaluate the effect of mucin and protein binding on antibiotic activity. Two to three bacterial colonies were inoculated into 10 mL CAMHB and incubated at 35° C. in a shaking water bath (250 rpm) for 18-24 hours. A 1:40 dilution of the overnight culture was made in 10 mL of fresh CAMHB and incubated at 35° C. in a shaking water bath (250 rpm) for 1-2 hours. The resulting culture was adjusted to a 0.5 McFarland standard (NCCLS, 2003). To reduce variability in the bacterial inoculum size when comparing multiple antibiotics, one master tube of CAMHB containing 2% (weight/volume) of porcine gastric mucin was inoculated with a 1:200 dilution of bacterial inoculum (approximately 5×105CFU/mL), supplemented with 25 μg/mL of glucose-6-phosphate, and briefly vortexed. Ten milliliter aliquots were then pipeted into 50 ml, conical tubes. Fosfomycin alone, tobramycin alone, and combinations of fosfomycin plus amikacin, arbekacin, dibikacin, gentamicin, kanamycin, netilimicin, neomycin, streptomycin, or tobramycin were added to the culture medium at concentrations equal to 1, 2, 4, and 8-fold multiples of the fosfofomycin MIC (4 μg/mL) for The MBCs of fosfomycin, amikacin, arbekacin, dibikacin, gentamicin, kanamycin B, netilimicin, neomycin, streptomycin, or tobramycin alone for The frequency of single-step spontaneous resistance mutation was determined for 5 susceptible Development of resistance during continuous serial passage was evaluated with a clinical The in vivo efficacy of aerosolized fosfomycin alone, tobramycin alone and combinations of fosfomycin plus tobramycin were evaluated against Prior to intratracheal installation of the bacterial inoculum, male Sprague-Dawly rats (200-250 g) were anesthetized by exposure to isoflurane for 5 minutes. An intratracheal needle was inserted into the trachea and 80 μl of agarose beads containing approximately 10-100 CFU of Fosfomycin alone, tobramycin alone, and fosfomycin:tobramycin combinations were administered to rats using an aerosol exposure device (In Tox Products, New Mexico). The system consisted of a central chamber having separate aerosol supply and exhaust paths. The central chamber had 24 ports that were directly connected to the aerosol supply system. Rats were placed into individual aerosol exposure tubes and restrained with an adjustable push plate and end cap assembly so they could not turn around or back away from the end of the tube. The restraint tubes containing the rats were loaded onto ports on the central chamber and the air flow adjusted to 1 liter/min. The air (breathable quality air) flow to the PARI LC Star nebulizer was held constant at 6.9 liters per minute. Fosfomycin alone, tobramycin alone, or 9:1, 8:2, or 7:3 fosfomycin:tobramycin combinations were nebulized at 0.2 mL/min and delivered to the rats via the aerosol supply path. Additional air (hereafter referred to as dilution air) was delivered to nebulizer (where) to balance the over pressure of the air used to deliver aerosolized drugs to the rats. Rodents were exposed to aerosolized antibiotics for up to 2 hours, twice daily for 3 consecutive days. Each treatment group consisted of 5-8 animals per group. A non-treatment control was included in each experiment. Bacterial killing was evaluated 18 hours after the last exposure. Rats were anesthetized with isoflurane and euthanized by intraperitoneal administration of 500 μl of phenobarbitol. The lungs were removed aseptically, excess tissue removed and the lung weight determined. Lungs were placed in 10 mL glass vials, and 3 mL of normal sterile saline added per gram tissue. Samples were homogenized with hand-held homogenizer for 30 seconds. Bacterial killing was determined by making 10-fold serial dilutions of the lung homogenate in sterile normal saline, and spreading 100 μl aliquots on blood agar plates. Culture plates were incubated at 35° C. for 18-24 hours and the number of bacterial colonies enumerated manually. Antibiotic efficacy was determined by comparing the CFU's/lung from the non-treatment control group to the treatment groups. Conway, S P., K G Brownlee, M Denton, and D G Peckham. 2003. Antibiotic treatment of multidrug-resistant organisms in cystic fibrosis. Am J Respir Med 2(4):321-332.
Perri, M. B., E. Hershberger, M. Ionescu, C. Lauter, and M. J. Zervos. 2002. In vitro susceptibility of vancomycin-resistant enterococci (VRE) to fosfomycin. Diagn. Microbiol. Infect. Dis. 42:269-271.
CROSS-REFERENCE TO RELATED APPLICATION
FIELD OF THE INVENTION
BACKGROUND OF THE INVENTION
SUMMARY OF THE INVENTION
BRIEF DESCRIPTION OF THE DRAWINGS
DEFINITION OF TERMS
DETAILED DESCRIPTION OF THE PREFERRED EMBODIMENT
MIC values of fosfomycin and tobramycin alone and in combination against Gram-negative bacteria. MIC (μg/mL) Bacteria Fosfomycin Tobramycin F9:T1 F7:T3 F5:T5 COR-003 16 0.5 8 4 1 COR-009 1024 2048 1024 512 2048 COR-021 8 64 8 8 8 COR-027 128 0.5 8 2 1 COR-032 1 0.5 1 1 1 COR-039 64 0.25 2 0.5 0.5 COR-040 1 32 1 1 2 COR-042 8 0.5 4 2 1 COR-049 128 0.5 4 1 1 COR-090 ≧2048 128 1024 ND ND COR-098 ≧2048 64 1024 ND ND COR-082 128 4 4 4 8 COR-083 64 512 256 128 128 COR-087 ≧512 128 128 128 128 COR-042 8 0.5 4 2 1 COR-049 128 0.5 4 1 1 COR-109 4 8 4 ND ND COR-113 4 8 4 ND ND ND = Not determined. MIC values of fosfomycin and tobramycin alone and in combination against Gram-positive bacteria. MIC (μg/mL) Bacteria Fosfomycin Tobramycin F9:T1 F7:T3 F5:T5 COR-051 1 0.25 2 1 0.5 (MSSA) COR-055 4 0.25 4 1 0.5 (MRSA) COR-059 2 128 2 4 4 COR-060 2 64 1 4 8 (GISA) COR-061 32 64 16 32 32 COR-068 8 16 16 16 16 COR-104 64 32 ND ND ND COR-105 16 64 ND ND ND COR-099 32 512 ND ND ND COR-103 32 8 ND ND ND ND = Not determined. MIC values of fosfomycin and tobramycin alone and in combination for 100 MIC50(μg/mL) MIC90(μg/mL) Antibiotic Mucin (−) Mucin (+) Mucin (−) Mucin (+) Fosfomycin 64 64 ≧512 128 Tobramycin 2 16 16 64 F9:T1 16 32 64 128 F8:T2 8 32 64 128 F7:T3 8 16 64 64 Checkerboard studies between fosfomycin and various aminoglycosides for Antibiotic Combination Interaction Fosfomycin:Tobramycin Indifferent Fosfomycin:Gentamicin Indifferent Fosfomycin:Arbekacin Indifferent Fosfomycin:Dibekacin Indifferent Fosfomycin:Kanamycin B Indifferent Fosfomycin:Streptomycin Indifferent Fosfomycin:Amikacin Indifferent Fosfomycin:Neomycin Indifferent Fosfomycin:Netilmicin Indifferent Checkerboard studies between fosfomycin and tobramycin for and Antibiotic Interaction Bacterial Syner- Addi- Indif- Antag- Strains N = gism tion ference onism 17 1 0 16 0 5 1 0 4 0 1 0 0 1 0 4 0 0 4 0 MBC/MIC values of aminoglycosides alone and 9:1, 8:2, and 7:3 combinations of fosfomycin and aminoglycoside for MBC/MIC Antibiotic Amino- Combination glycoside F9:A1 F8:A1 F7:A3 Fosfomycin:Tobramycin 1 1 1 1 Fosfomycin:Gentamicin 2 4 2 8 Fosfomycin:Amikacin 2 4 4 2 Fosfomycin:Netilimicin 1 2 4 2 Fosfomycin:Arbekacin 1 4 4 2 Fosfomycin:Streptomycin 4 2 2 2 Fosfomycin:Neomycin 2 2 2 4 Fosfomycin:Kanamycin B ND 4 2 4 Fosfomycin:Dibekacin 1 4 2 1 ND = Not determined “F” = Fosfomycin and “A” = aminoglycoside MBC/MIC values of fosfomycin and tobramycin alone and 9:1, 8:2, and 7:3 combinations of fosfomycin and tobramycin. MBC/MIC Antibiotic Fosfomycin ≧8 8 1 Tobramycin 1 1 8 F9:T1 1 1 2 F8:T2 1 2 4 F7:T3 1 2 4
b. Killing Rates
Time-kill studies with 9:1, 8:2, and 7:3 fosfomycin:aminoglycoside combinations against were evaluated at a concentration of 32 (μg/mL) Antibiotic Synergy Combination F9:A1 F8:A2 F7:A3 Fosfomycin:Tobramycin Yes No No Fosfomycin:Gentamicin Yes No No Fosfomycin:Amikacin No No No Fosfomycin:Netilimicin No No No Fosfomycin:Arbekacin No No Yes Fosfomycin:Streptomycin No No No Fosfomycin:Neomycin No No No Fosfomycin:Kanamycin B No No No Fosfomycin:Dibekacin No No No “F” = Fosfomycin and “A” = aminoglycoside Time to reach bactericidal killing of by 9:1, 8:2, and 7:3 fosfomycin:aminoglycoside combinations. Antibiotic Time (h) Combination F9:A1 F8:A2 F7:A3 Fosfomycin:Tobramycin 2 1 1 Fosfomycin:Gentamicin 6 4 2 Fosfomycin:Amikacin 4 4 2 Fosfomycin:Netilimicin NC NC 6 Fosfomycin:Arbekacin NC 4 2 Fosfomycin:Streptomycin NC NC NC Fosfomycin:Neomycin NC NC NC Fosfomycin:Dibekacin NC 4 4 “NC” refers to not cidal “F” = Fosfomycin and “A” = aminoglycoside Frequency of development of resistance to fosfomycin, tobramycin and a 9:1 fosfomycin:tobramycin combination. Frequency of Resistance Strains Fosfomycin Tobramycin Fos + Tob COR-002 1.4 × 10−3 6.7 × 10−6 <2.9 × 10−8 COR-003 5.5 × 10−4 3.2 × 10−6 <1.2 × 10−9 COR-013 6.4 × 10−3 2.6 × 10−6 2.0 × 10−7 COR-014 1.5 × 10−5 5.0 × 10−6 <1.4 × 10−9 ATCC 27853 4.1 × 10−5 3.4 × 10−6 <2.5 × 10−9 Fold increase in MIC after a single exposure to antibiotic. Fold Increase in MIC Strain F9:T1 Fos Tob COR-002 1 >256 1 COR-003 2 >256 2 COR-013 1 >64 8 COR-014 1 >512 16 ATCC 27853 2 128 1 Development of resistance after continuous exposure to antibiotic. MIC (μg/mL) Antibiotic 0 d 7 d 14 d 21 d 28 d F9:T1 8 16 64 64 64 Tobramycin 0.5 0.5 0.5 32 64 Fosfomycin 16 >512 >512 >512 >512
d. Animal Efficacy
EXAMPLE 1
Preparation of Fosfomycin/Tobramycin Solutions for Aerosolization
8:2 Fosfomycin/Tobramycin Solution A solution of fosfomycin/tobramycin in a 8:2 ratio was prepared. 3.1680 g of fosfomycin disodium (2.4013 g free acid) was dissolved in 50 ml water. 0.6154 g of 97.5% tobramycin base (0.6000 g of pure tobramycin base) was dissolved in the fosfomycin solution. The pH adjusted by adding 0.910 mL of 6 M HCl. The solution was diluted to 100 mL with water. The final pH of the solution was 7.65, osmolality was 477 mOsmol/kg, and the chloride concentration was 54.6 mM. The final fosfomycin/tobramycin ratio was calculated to be 8:2
7:3 Fosfomycin/Tobramycin Solution Using the procedure described for the 9:1 solution, above, a solution of fosfomycin/tobramycin in a 7:3 ratio was prepared; 17.466 g of fosfomycin disodium (13.239 g free acid) was dissolved in water; the pH adjusted to 7.43 by adding 1.46 mL of 4.5 N HCl, 5.819 g of 97.5% tobramycin base (5.674 g of pure tobramycin base), and the pH of the combined solution was adjusted by adding 9.20 mL of 4.5 N HCl. The final pH of the solution was 7.68, the osmolality was 560 mOsmol/kg, the fosfomycin/tobramycin ratio was 7:3, and the chloride concentration was 95.9 mM.
EXAMPLE 2
Preparation of A 8:2 Hyperosmolar Solution of Fosfomycin and Tobramycin
EXAMPLE 3
Preparation of Individual Solutions of High pH Fosfomycin and Low pH Tobramycin for Reconstitution
EXAMPLE 4
Preparation of an 8:2 Fosfomycin/Tobramycin Solution from Commercial Tobramycin for Inhalation Solution (TOBI) and Lyophilized (Dry) Fosfomycin Disodium (FOSFO)
EXAMPLE 5
Determination of Minimal Inhibitory Concentrations (MIC)
Method B: The MICs of fosfomycin alone, tobramycin alone, or combinations of fosfomycin plus tobramycin were determined for
Method C: The MICs of amikacin, arbekacin, dibekacin, gentamicin, kanamycin, netilimicin, neomycin, streptomycin, and tobramycin alone were determined for EXAMPLE 6
Checkerboard Synergy
EXAMPLE 7
Determination of Time-Kill Kenetics
EXAMPLE 8
Determination of Minimal Bactericidal Concentration (MBC)
EXAMPLE 9
Determination of Frequency of Single-Step Resistance
EXAMPLE 10
Multistep Resistance Analysis
EXAMPLE 11
Determination of Animal Efficacy
REFERENCES
